Flexible Installation.
Netplus smart gate controller is originally designed to be compatible with existing gate switches, keeping its mechnical function and at the minimum change of your current electrical system. Thanks to its miniature size, this smart gate module fits most of the flush mounted junction boxes, with no need of recontruction or rewiring.
Wi-Fi Connected.
Use your existing home Wi-Fi network to achieve wireless control.
Highly Compatibility.
This smart controller module is compatible with existing gate switches.
Time Schedule.
Create custom schedules based on your agenda or follow the sunrise or sunset.
Mobile App Remote Control.
Open or close your garage door or gate directly from mobile App, no matter where you are. One courier is delivering the TV you bought online, but you’re not at home. Are you worried that the TV may be stolen if it is left in the porch. Now take out of your smartphone to open your garage door and let the TV unloaded in the garage.
Hand-free Voice Control.
Netplus smart gate control module works with amazon Alexa/Echo/Dot, Siri, Google Home, Yandex, etc. After pairing with them, you can control your garage door or gate with simple voice commands, no need to touch a switch or open the app, just ask Alexa to proceed commands.
Device Sharing.
Add your family members in the sharing list, then they are capable of controlling the same devices.
Smart Scenarios.
Create smart scenarios by linking the smart gate controller with other Netplus smart devices. Set the smart controller to activate custom scenes based on temperature, humidity, light, or various occurrences. Use Netplus gate smart module to open your swing gate when you drive home, then smart switch turn on lights, air conditioning during the period of parking car.
Features:
- Input: AC100-240V 50/60Hz
- Output: 3.30V
- Channels: 1 channel
- Sensors Included: Yes
- Power Measurement: No
- Management App: SmartLife or TuySmart App
- Operation Range: < 200 meters
- Standby Power: < 0.5W
- Overload Protection: Yes
- Neutral Wire Required: Yes
- Connectivity Protocol: Wi-Fi 2.4GHz & Bluetooth
- Wireless Standard: IEEE 802.11 b/g/n
- Antenna: A ceramic antenna integrated on PCB board
- Security Module: WPA / WPA2
- Encryption Type: WEP / TKIP / AES
- Operation Temperature: -10ºC – +40ºC
- Case Temperature: Tc: +80ºC (Max.)
- Working Humidity: 5% – 95% RH, non-condensing
- IP Rating: IP20 for indoor use
