Combined smoke and heat detector

€83.64 incl tax

The detector indicates fire hazards using the built-in LED indicator and alarm outputs ALARM and TAMPER. These outputs must be connected to control panels complying with EN 50131-3.
The SD-282 ST consists of two independent detectors – an optical smoke detector and a heat detector. The optical smoke detector works on the principle of scattered light and is very sensitive to dust particles which are present in smoke. There is also a built-in heat detector for detecting fire which generates heat quickly with a small amount of smoke. The microprocessor performs digital analysis for a high false-alarm immunity.

SKU: SD-283ST

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Availability: 1 in stock

Qty:

Overview
Reviews
Contact Us

TechInfo:

Power: 9-15V DC / 5 mA;
Smoke detection: optical light scattering;
Smoke detector sensitivity: m = 0.11 - 0.13 dB/m pursuant to EN 54-7;
Heat detection: class A2 according to EN 54-5;
Alarm temperature: + 60°C to + 70°C;
Operating temperature range: -10 to +80°C;
Dimensions, weight: diameter 126 mm, height 65 mm, 150 g;
Conformity: EN 54-7, EN 54-5, EN 50130-4, EN 55022;
