Characteristics
functions
for switch, rheostat and blind functions
Commands and Indicators
Manual operation can be activated by selecting the switch, performing the deactivation of the KNX function
with programming button and red programming LED
Voltage
BUS operating voltage: 21…32 V DC
System supply voltage: 30 V DC via bus
electric current
Number of input circuits: 6
Length
Maximum connection distance between receiver and transmitter: 100m
Power
Total power dissipated in IN: 0.3 W
Materials, finish, colors.
color Gray
dimensions
Width: 2 modules
lighting management
Brightness measurement range: 2 / 20000 Lux
Gloss measuring range, linear: 2…20000 lx
LED lighting management
LED: with 2 status LEDs
Connection
Flexible cable connection section: 1/6mm²
Rigid cable connection section: 1.5 / 10mm²
Connection type: screw terminal block
-with integrated bus coupling unit
-with screw terminals
-bus connection via terminal
settings
Possible configuration modes: system, easy
Brightness modifiable by potentiometer
Equipment
Number of channels: 1
Probes to associate: EE002 - EE003
six brightness threshold values for independent activation of the switching channels
Terms of use
Operating temperature: 0…45 °C
Storage / transport temperature: -20…70 °C
